Heave Duty 45cbm 80 Ton Side Tipper Trailer

China Shandong Fudeng Automobile Co., Ltd produced by the side dump semi trailer, large capacity, strong power, durable, affordable, is your best choice to transport goods
Capacity:
Paylod:
Usage:
Discharge type:
Axle brand:
Availability:
  • Side tipping trailer
  • Fudeng

Product Description

Heave duty 45cbm 80 ton Side tipper trailer

Heave Duty 45cbm 80 Ton Side Tipper Trailer

The square shape side tipper semi-trailer can be used for the transportation of coal, ore, building materials and other goods. Compared with U-shaped dump semi-trailer, square dump semi-trailer can be reused for a long time because it has a stronger frame. The square shape side dump semi-trailer can quickly fill and unload the cargo, which can meet the personalized needs of customers.

福121




Specification

Side Tipping Trailer Specifications

Body

Dimension

11000*2500*3300mm

Payload

70000 KGS

Box dimension inside

10900*2400*1600mm

Box thickness

Side 6mm, bottom plate 8mm

Hydraulic cylinder

5 side tipping cylinder +1 shifting cylinder, can unload both sides

Tare weight

About 11000kg

Chassis

Frame

Welding design or Special design beam, connected by bolts and nuts, Q345B steel material

Frame Beam

Upper plate is 14mm and lower is 16 mm, middle is 8 mm. height is 500 mm

Axle

3 axles

Landing Gear

Standard 28T JOST brand

King Pin

2.00(5.0) or 3.5 (9.0) JOST brand

Suspension

Mechanical suspension

Leaf Spring

90mm(W)*16mm(T)*10 Layer

Pneumatic Braking System

8 air chamber, 3 axles synchronization WABCO brand

Rim

8.25-20, 8.25-22.5,

Tire

315/80 R 22.5, 12 R 22.5

ABS

KEMI brand

Accessories

One standard tool box

Voltage

24V

Packing and shipping

Painting

Complete Chassis sand blasting to clean rust, 2 coat of anticorrosive prime, 1coats of final paint

Shipping Terms

By Bulk Cargo/RORO



FAQ

Q1. How will I conduct the transaction?

(1)We need to confirm the trailer specification then send you best quote, and we can confirm the payment, delivery time, order amount and production time together, after all confirmed I will send you the proforma invoice with our factory bank details.

(2)If PI is ok, you can arrange 30% deposit to our factory bank account, and provide me the bank slip.

(3)After received deposit, start arrange production. And will send you trailer pictures or videos during the production.

(4)After finish production, we will inform you to pay 70% balance. When balance received start to arrange shipping. Then send original documents by DHL, And we will keep you updated estimated time of arrival.



Q2. What’s your payment terms?

A:Our payment term is 100% T/T. 30% deposit before production, will send you pictures or video after finish production to let you confirm, and you will arrange 70% balance before shipment. After balance received, we will help you book the latest ship as soon as possible.
