China Popular 3axles Side Wall Semi Trailer with Detachable Panel

The Side wall semi trailer is made of high tensile steel. The Main beam is “I” shape beam, which have better load-bearing properties while maintaining resistance to deformation. The Side wall semi trailer is mainly used to transport bulk goods, but we can also install container twist locks according to your requirements. In this way, when you remove the side panel, it becomes a flatbed trailer, and you can transport 40ft and 20ft containers, realizing multiple functions.

Availability:

Product Description

    The Side wall semi trailer is made of high tensile steel. The Main beam is “I” shape beam, which have better load-bearing properties while maintaining resistance to deformation. The Side wall semi trailer is mainly used to transport bulk goods, but we can also install container twist locks according to your requirements. In this way, when you remove the side panel, it becomes a flatbed trailer, and you can transport 40ft and 20ft containers, realizing multiple functions.


Dimension

12.5m×2.5m×1.55m (Outside)

Payload

60T

Tare weight

About  7.5T

Main beam

Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B,

welded by automatic Submerged-Arc processes.

Frame Beam

Top Flange 14mm,width 140mm; Middle

Flange 8mm; Bottom Flange 16mm,width 140mm, main beam height  500mm

Frame Floor

The Thickness is 3mm pattern

Edge beam

16# Channel

Through beam

10# Channel

Along beam

6# Channelx6

Axle

3 axles, 13T FD brand 16ton brake pads

Landing Gear

28T lifting capacity with two speed


China heavy duty 3axles Side wall semi trailer Double -tyres for sale


栏板水印01


栏板水印08


     Our factory supports customization, whether it is axles, tires, suspension or other configurations, we will meet your requirements. At the same time, if you also have requirements for the side panel, we can also change it, whether it is 0.4 meters, 0.6 meters or 0.8 meters, etc., all can be customized. We are looking forward to cooperating with you.


栏板水印05


FUWA axle Double-tyres 12R22.5 Tubeless tyres on your requirments


栏板水印07

    If you are interested in our products, please feel free to contact us at any time. Shandong Fudeng Automobile Co., Ltd. will provide you with better services and great prices. We are looking forward to cooperating with you.
