China 3 Axles U Shape End Dump Tipper Trailer for Sale

There are two main types of Rear dump semi trailer, U-shaped and square-shaped. They work similar, but people have different preferences in different places. Whether you like U-shaped or square-shaped Rear dump trailer, our factory can meet your needs.

Dimension: 10.3m*2.5m*3.3m (Outside) Or Customized

Box Dimension: 9.6m*2.3m*1.8m  40Cubic

Payload: 60T

Tare weight: About 12T

Lifting brand: HYVA 196 or CHINA 191

Availability:

Product Description

     In factory production, most of the dumpers are 30 square meters and 35 square meters. But if you want a larger cubic meter of rear tip bucket, we also support customization to increase the volume of the rear tip bucket. There is a front bezel in front of the rear tipping dump truck body, which can effectively protect the oil cylinder and the front cab, and prevent the cargo from falling and hitting the front cab and the hydraulic cylinder during transportation, causing unnecessary losses.


Frame

Welding design or Special design  Two beams.Square beam, connected by bolts and nuts, Q345B carbon steel material

Frame Beam

Upper and lower plate is 14mm and 16mm, Double middle is 8 mm.Height is 500 mm

Steel thickness

Bottom plate :5mm Side plate:4mm

Axle

3 axles, 13T FD Brand Axles 16ton brake pads

Landing Gear

28T lifting capacity with two speed

King Pin

2.00 or 3.5 inch bolt-in king pin

Suspension

Mechanical suspension

Leaf Spring

90mm(W)*16mm(T)*10 Layer

Pneumatic

Dual line pneumatic brake system,T30/30+T30 air chamber ,40L air tanks,Emergency relay valve

Tire

315/80R22.5*12pcs Or Optional

Accessories

One standard tool box

Electrical system

24 volt electrical system.7 pin electrical connector. Parking .stop,reverse,number plate and indicator lights. rear lights conform to European standard, rear front and side reflectors


3axles U shape rear dump semi trailer for sale in Africa


后翻U型水印10


后翻U型水印11


    Due to the different goods being transported, the thickness of the rear tip bucket is different. For example, for the transportation of soil and sand, the thickness of the bottom plate of the trailer body is 4 mm, and the thickness of the side plate is 3 mm. But for transportation such as gravel, the bottom plate is generally 8 mm thick, and the side plates are 6 mm thick. For the transportation of larger stones, the bottom and side panels will be thicker. We need to further confirm these with you and recommend the right dumper for you.


后翻U型水印12


后翻U型水印01

    Shandong Fudeng Automobile Co., LTD, located in Jinan Shandong province China. Engaged in a variety of truck, trailer production, sales activities. With professional team and excellent products, we sincerely look forward to cooperating with customers all over the world. If you are interested in our products or have any questions, please contact us, we will reply as soon as possible.
