Product Description
Widely praised as the industry’s most cement dry bulk trailers, Fudeng Trailer offers vessel integrity, low tare weights, high efficiency, long wear, easy clean-out and Fudeng Trailer craftsmanship throughout, to keep your operation running at maximum efficiency. Fudeng Trailer dry-bulk trailers have all the qualities desired in an efficient solution, It’s Fudeng Trailer craftsmanship, combined with the exceptional durability, thoughtful engineering and high payloads customers have come to expect from every premium Fudeng Trailer product—peace of mind that frees you up to focus on the most important project of all—building your business.
1. The bulk cement trailer is made by advanced technique from both Europe and China.
2. Air compressor adopts special no lubrication vehicle air compressor for bulk cement trailer.
3. Key parts of the bulk cement trailer have been equipped with high quality fittings purchased from those famous brands both at home and aboard.
4. Tank body is welded by co2 automatic welder.
5. Safe and reliable driving for bulk cement trailer
6. Easy maintenance and convenience for bulk cement trailer
50 cbm 60 ton transport bulk cement tank trailer Specifications | |
Tank Body | |
Shape | V shape customized |
Dimension | 13000*3990*2500mm |
Capacity | 50 cbm 60 ton |
Tanker Body | 5mm Q345B |
End Plate | 6mm Q345B |
Manhole Cover | 2 or 3 pieces |
Air Compressor | Wuhu Fuda 12 cbm double-cylinder, Working pressure 0.2 MPa, Testing pressure 0.3 MPa |
Diesel Engine | Weichai 4102 or 4105 |
Chassis | |
Main Beams | Q345B high- insensitive steel Upper plate is 14mm and lower is 16mm,middle is 8mm. height is 500 mm |
Axle | 3 axles, 13T American type, 16T brake block, Fuwa brand |
Landing Gear | Standard 28T Jost brand |
King Pin | 5.0(2 inch)/9.0(3.5 inch) bolt Jost brand |
Suspension | Mechanical suspension |
Leaf Spring | 90mm(W)*16mm(T)*10 Layer |
Pneumatic Braking System | 6 air chamber, 3 axles synchronization Webco brand |
Rim | 9.00-22.5/8.00-22.5/8.5-22.5 |
Tire | 11.00R22.5/12.00R22.5 Triangle brand |
ABS | KEMI Optional |
Accessories | standard tool box, Spare Tire Rack, Radiator Optional |
50 cbm 60 ton transport bulk cement tank trailer pictures to refer
65 cbm 80 ton transport bulk cement tank trailer
Fudeng brand bulk cement tank trailer shipping
